Name: Rivers and Streams Symbolized

Display Field: NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>Hydro Stream is a measured linear GIS feature class derived from the NHD (National Hydrography Dataset) and extensively edited to include specific data from IDFG (Idaho Fish and Game) hydro (hydrography) data. The project was initiated in 2008 with the objective of updating the 1:100k resolution IDFG measured stream hydro to more closely align with the 1:24k NHD hydro. Because the merging process is complex and the IDFG hydro is actively edited, continuing efforts toward the orginal merger for common use was deemed impractical (2016ccoulter) for the following partial list of reasons:</SPAN></P><P><SPAN>Just as the IDFG stream hydro is actively edited internally, the NHD flowline is actively edited by internal and external users, so both datasets are in continual transition. Further complicating the merge process, the (now archived) IDFG Hydro_Stream_Measured is a whole-stream dataset based on LLID (a concatenation of Longitude and Latitude at the mouth of a stream at the time of feature creation), where NHD is a multi-segmented dataset based on GNIS (Geographic Names Information System) names and other unique numbers used presumably by hydrologists and the data managers who developed it. The technical nature and number of fields inherent to the parent dataset are extraneous to needs of IDFG end users, which would have necessitated additional processing to eliminate those fields. Because IDFG streams for in-house mapping and online reference must render quickly, the number of records in NHD required to display a unique stream impair the speed requirement. Finally, although they were eventually added, the initial lack of date, edit, and note fields in the interim IDFG stream hydro dataset to track what has been edited, when, or by whom complicated management. The emerging measured stream dataset here is based on NHD comparisons and IDFG adjustments.</SPAN></P><P><SPAN>BACKGROUND: Bart Butterfield (et al) developed the original stream geometry and dataset in the 1990s; Tim Williams implemented methods for transferring data from the old to the new system beginning in 2008 with the assistance of Cyndi Coulter. These efforts have been laborious and time-consuming and have taken place over the past decade-plus (ccoulter2019Aug14). Mr. Williams departed suddenly in May 2015 when the new system was nearing roll-out, although many fixes remained to be addressed. Ms. Coulter assumed management of the stream and lake hydro data following Mr. Williams' departure. A concerted effort to resolve lingering inconsistencies took place throughout 2018 and the resulting stream hydro was rolled out in early 2019. Although many issues persist, significant efforts have resolved disparities between IDFG and NHD stream hydro data, as well as a high number of adjustments to the IDFG hydro that will not align with NHD line work. These include both corrections and internal requests for management purposes.</SPAN></P></DIV></DIV></DIV>

Service Item Id: ae63e9a9b8c541b8be387608d56b6e8b

Copyright Text: Idaho Department of Water Resources, United States Geological Survey, StreamNet, Idaho Department of Fish and Game, Idaho Fish and Wildlife Information System, National Hydrography Dataset

Default Visibility: false

MaxRecordCount: 35000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.3813039171500001E7
YMin: 5077118.662699997
XMax: -1.23134315566E7
YMax: 6822261.237599999
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: FCode
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
Style: esriSLSSolid
Color: [0, 197, 255, 255]
Width: 1
Default Label: Streams
UniqueValueInfos:
• Value: 33600
  Label: Canals
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [115, 178, 255, 255]
  Width: 1
• Value: 33601
  Label: Canals
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [115, 178, 255, 255]
  Width: 1
• Value: 42801
  Label: Canals
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [115, 178, 255, 255]
  Width: 1
• Value: 42813
  Label: Canals
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [115, 178, 255, 255]
  Width: 1
• Value: 46000
  Label: Canals
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [115, 178, 255, 255]
  Width: 1
• Value: 45500
  Label: Rivers
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [115, 178, 255, 255]
  Width: 2
• Value: 55800
  Label: Rivers
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [115, 178, 255, 255]
  Width: 2
• Value: 46003
  Label: Intermittent
  Description: N/A
  Symbol:
  Style: esriSLSDashDot
  Color: [115, 178, 255, 255]
  Width: 1
• Value: 46007
  Label: Intermittent
  Description: N/A
  Symbol:
  Style: esriSLSDashDot
  Color: [115, 178, 255, 255]
  Width: 1
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• LLID ( type: esriFieldTypeString, alias: LLID, length: 13 )
• FType ( type: esriFieldTypeInteger, alias: FType )
• FCode ( type: esriFieldTypeInteger, alias: FCode )
• NAME ( type: esriFieldTypeString, alias: NAME, length: 50 )
• VARIANT ( type: esriFieldTypeString, alias: VARIANT, length: 50 )
• SECTION_ ( type: esriFieldTypeString, alias: SECTION_, length: 256 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• PName ( type: esriFieldTypeString, alias: PName, length: 120 )
• PLLID ( type: esriFieldTypeDouble, alias: PLLID )
• Note ( type: esriFieldTypeString, alias: Note, length: 240 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• Maj_Trib ( type: esriFieldTypeSmallInteger, alias: Maj_Trib )
• LLIDNum ( type: esriFieldTypeString, alias: LLIDNum, length: 17 )
• GNIS_ID ( type: esriFieldTypeInteger, alias: GNIS_ID )
• GNIS_Name ( type: esriFieldTypeString, alias: GNIS_Name, length: 50 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
